| Brand Name: | HONORWAY |
| Model Number: | HW-5680 |
| MOQ: | 1 |
| Price: | $20-25 |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs per month |
| Reading Performance | Specifications |
|---|---|
| Image Sensor | CMOS |
| Resolution | 752×640, 60fps |
| Decoding Capacity | 2D Codes: QR, Micro QR, PDF417, Micro PDF417, Data Matrix, MaxiCode, Aztec, Hanxin 1D Codes: UPC-A, UPC-E, EAN-13, ISBN10, ISBN13, EAN-8, Code 39, Code 11, Code 93, Code 128, and all standard 1D formats |
| Precision | 4mil @ Code 39, PCS=90% |
| Light Source | 630nm Visible Red Diode |
| View Angle | 76.7°(H) × 53.4°(V) |
| Scan Angle | Rotation 360°, tilt ±65°, skew ±65° |
| Scan Speed | 400 times/second |
| Trigger Mode | Continuous scan / Auto Detective |
| Depth of Field | 15-150mm (depending on barcode type and quality) |
| Mechanical & Electrical | Specifications |
| Interface | USB, USB COM, RS232, TTL232 |
| Working Voltage | 5VDC ±5% |
| Operation Current | 240mA ±5% |
| Dimensions | 149(H)mm × 98(W)mm × 70(D)mm |
| Weight | 260g (without cable) |
| Indication | LED & Buzzer |
| Environmental Requirements | Specifications |
| Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -40℃ to +70℃ |
| Humidity | 5%-95% (Non-condensing) |
| Ingression Protection | IP43 |
| Light Level | Max 100,000 Lux (fluorescence) |
| Shock Resistance | Designed to withstand 1.5 meters drop on concrete surface |
