| Brand Name: | HONORWAY |
| Model Number: | HW-5620B |
| MOQ: | 2 |
| Price: | $25-30/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs/month |
| Image Sensor | CMOS |
| Resolution | 640 x 480 @ 60fps |
| Decoding Capability | Paper and screen barcodes |
| 2D Barcode Support | QR, Micro QR, DataMatrix, PDF417, MicroPDF417, Aztec, Maxi Code, Hanxin |
| 1D Barcode Support | UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11, Codabar, GS1 Data Bar, GS1 Composite, Plessey, Febraban |
| Precision | 4mil @ Code 39, PCS=90% |
| Light Source | 617nm Visible Red Diode |
| View Angle | 53°(H) x 41°(V) |
| Scan Angle | Rotation 360°, tilt ±60°, skew ±65° |
| Scan Speed | 300 scans/second |
| Contrast Rate | ≥25% |
| Trigger Mode | Auto Detective, Continuous Mode |
| Scan Distance | 4mil (Code 39): 0-55mm, 13mil (UPC): 0-250mm, 12.5mil (Code 39): 0-200mm, 20mil (QR): 0-150mm |
| Interface | HID/SPP/BLE + 2.4G + USB |
| Working Voltage | 5VDC ±3% @ 1A |
| Transmission Range | Bluetooth ≤15m, 2.4GHz ≤30m |
| Storage Capacity | 16MB (2,000 barcodes ≤500 characters) |
| Battery Capacity | 1500mAh |
| Dimensions | 140 x 85 x 85mm |
| Weight | 260g |
| Indication | LED & Buzzer |
| Operating Temperature | -10℃ to +50℃ |
| Storage Temperature | -30℃ to +60℃ |
| Humidity | 5%-95% (Non-condensing) |
| Ingress Protection | IP43 |
| Light Level | 0-100,000 Lux |
| Shock Resistance | Withstands 1.5 meter drop on concrete surface |
