| Brand Name: | HONORWAY |
| Model Number: | HW-3960B |
| MOQ: | 1 |
| Price: | $16-26 per pcs |
| Payment Terms: | T/T |
| Supply Ability: | 20Kpcs per month |
| Model Number | Interface | Battery | Charging Base |
|---|---|---|---|
| HW-3900 | USB or RS232 | / | / |
| HW-3900W | 2.4GHz wireless (USB dongle),wired | 2200mAh | / |
| HW-3900B | 2.4GHz wireless + Bluetooth,wired | 2200mAh | / |
| HW-3960W | 2.4GHz wireless,wired | 2200mAh | Yes |
| HW-3960B | 2.4GHz wireless + Bluetooth,wired | 2200mAh | Yes |
| Stand | / | / | / |
| Image Sensor | CMOS global shutter 60fps |
| Resolution | 0.3MP 640*480 pixels |
| Decoding Capacity | Supports paper and screen barcodes |
| 2D Barcodes | QR, PDF417, Data Matrix (normal+inversed), Aztec, Maxi code, etc. |
| 1D Barcodes | UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Code 11, Interleaved 2of 5, Industrial 2 of 5, Matrix 2 of 5, Standard 2 of 5, Codabar, MSI Plessey, GS1, and all normal 1D formats |
| Precision | 3mil |
| Light Source | 617nm Visible red LED, white LED |
| Scan Angle | Rotation 360°, tilt ±60°, skew ±60° |
| Min Contrast | 25% |
| Scanning Speed | 500 times/s |
| Typical DOF | 40-100mm (4mil code39), 50-250mm (13mil EAN13), 40-300mm (20mil QR), 40-280mm (10mil PDF417) |
| Interface | USB/USB COM, RS232 (wired), Bluetooth, 2.4GHz RF wireless |
| Bluetooth Mode | HID SPP BLE |
| Working Voltage | DC 5V±5% |
| Current | 200mA (working), 10mA (standby) |
| Battery | 2200mAH lithium battery, working 3-7 days, charge time 4-5 hours |
| Memory Size | 16MB for 10K pieces @code128 |
| Dimensions | 170*65*100mm (scanner), 120*95*65mm (charging base) |
| Weight | 400g |
| Cable Length | 1.8M |
| Indication | Buzzer & LED |
| Working Temperature | -20~60℃ |
| Storage Temperature | -40~85℃ |
| Humidity | 5%-95% (Non-condensing) |
| Light Immunity | 0~100,000 Lux |
| Drop Test | 1.8M |
