| Brand Name: | HONORWAY |
| Model Number: | HW-3968B |
| MOQ: | 2 |
| Price: | $28/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs/month |
| Image Sensor | CMOS global shutter 100fps |
|---|---|
| Resolution | 752×480 pixels |
| Decoding Capacity | 2D: QR, PDF417, Data Matrix (normal+inversed), Aztec, Maxi code, dot code 1D: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Industrial 2 of 5, Matrix 25, Standard 25, Codabar, MS1I/MSI PLESSEY, GS1 DataBar Supports paper and screen barcodes, customized for OCRA, OCRB |
| Precision | 4mil for 1D, 6mil for 2D |
| Light Source | Position light-617nm Visible red LED, white LED |
| Scan Angle | Rotation 360°, tilt ±60°, skew ±60° |
| Min Contrast | 20% |
| Scanning Speed | 400 times/second |
| Typical DOF | Code128 10mil 18bytes: 80-270mm EAN13 13mil 13bytes: 40-300mm QR 20mil 11bytes: 10-230mm DM15mil 16bytes: 20-180mm Performance may be impacted by barcode quality and environmental conditions |
| Interface | USB/USB COM, RS232 (wired), Bluetooth, 2.4GHz RF wireless |
|---|---|
| Transmission Range | 70 meters (open air) |
| Bluetooth Mode | HID SPP BLE |
| Working Voltage | DC 5V±5% |
| Current | 250mA (working), 17mA (standby) |
| Battery | 2600mAh lithium battery |
| Charging Time | Base: <4 hours, Scanner: fast charging 24V@3A, <2 hours |
| Memory Size | 16MB for 10K pieces @code128 |
| Dimensions | 146.2×89.9×186.74mm |
| Weight | 219.2g |
| Cable Length | 1.8m |
| Indication | Speaker voice announcement Charging: solid red light, fully charged: red light off Dock mode: solid green light - dock connected, green light flashes - code read successful Standard Bluetooth: solid blue light - Bluetooth connected, blue light flashes - code read successful |
| Working Temperature | -30°C to 70°C |
|---|---|
| Storage Temperature | -40°C to 80°C |
| Humidity | 5%-95% (Non-condensing) |
| Light Immunity | 0-100,000 Lux |
| Drop Test | 1.2m, 6 sides, 10 times per side |
