86x86mm IP65 Waterproof Barcode Scanner Dual Frequency 13.56MHz 125KHz For Access Control

Name: 86x86mm IP65 Waterproof Barcode Scanner Dual Frequency 13.56MHz 125KHz For Access Control
Brand: Shenzhen Honor Way Electronic. Co., Ltd.
SKU: HW-1820
Price: 24.00 USD
Availability: InStock

Brand Name:	HONORWAY
Model Number:	HW-1820
MOQ:	1
Price:	$20-28/pcs
Payment Terms:	T/T
Supply Ability:	10kpcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE FCC ROHS ISO9001

Symbol:

1D Barcode, 2D QR Code

Frequency:

Dual,13.56MHz,125KHz Optional

Data Format:

Editable

Fill Light:

White LED

Size:

86*86*18mm

IP Protective:

IP65 Is Optional

Advatage:

Multiple Functions, Multiple Interface

Application Scenarios:

Hotel Room Door, Access Control

Packaging Details:

Paper Box

Highlight:

IP65 QR Barcode RFID Reader

Dual Frequency 13.56MHz 125KHz Barcode Scanner

Product Description

86×86mm Water Proof IP65 Barcode Scanner 13.56MHz NFC Mifare 125KHz EM Card Dual Frequency QR RFID Reader

Simplify your entrance management with the HW-1820, the intelligent reader that handles every credential type you need. Whether your users prefer physical cards (Mifare, EM) or the convenience of their phones (QR codes and NFC), this powerful device delivers fast, accurate recognition. Designed to cover all access control requirements, it perfectly bridges the gap between permanent user systems and flexible visitor management.

Key Advantages

All-in-One Efficiency: Replace clunky multi-device setups with one sleek reader, cutting costs and creating a cleaner, more user-friendly entry point.
Never Miss a Credential: Effortlessly read paper barcodes, RFID cards, and smartphone-based digital passes. It's the ultimate tool for hybrid environments.
Plug-and-Play Integration: Connect easily to your existing system through a wide selection of industry-standard interfaces including USB, RS485, and Wiegand.
Built to Last: Its compact, rugged design withstands heavy use. Custom sealing options provide IP65 waterproof protection for indoor or outdoor installations.

Technical Specifications

Barcode Reading Performance
Image Sensor	CMOS
Resolution	0.3MP 640×480 pixels
Decoding Capacity	Support paper and screen barcodes 2D: QR, PDF417, Data Matrix code, etc. 1D: UPC-A, UPC-E, EAN-8, EAN-13, Code128, Code39, Code93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, China post, etc.
Barcode Density	8mil
Light Source	624nm Visible red LED
Scan Angle	Rotation 360°, tilt ±45°, skew ±45°
Min Contrast	30%
Scanning Speed	200 times/s
Typical DOF	40-180mm (10mil code128) 45-200mm (20mil QR) Performance may be impacted by barcode quality and environmental conditions
Card Reading Performance
RFID Frequency	13.56MHz 125KHz optional
Card Type	EM card or Mifare card
Data Format	Default 8 bit Hex (format customized, like 10 bit 10 system, 10 bit Hex)
Reading Distance	0-50mm (depend on card type)
Reading Rate	106K/Bit
Reading Speed	0.1S
Interval	0.5S
Reading Time	≤100ms
Mechanical and Electrical
Interface	USB(COM), RS232, RS485, Wiegand
Working Voltage	DC 8-12V
Current	800mA (working)
Dimensions	86mm×86mm×18mm
Weight	150g (NW)
Indication	Buzzer & LED
Environment Requirements
Operation System	Windows, Android, Mac, Linux
Working Temperature	-20~60℃
Storage Temperature	-40~70℃
Humidity	5%-95% (Non-condensing)
Light Immunity	0~10,000Lux

Real-World Applications

At Corporate Turnstiles: Guide all users—employees with cards and visitors with QR codes—to the same reader for an intuitive, hassle-free entry experience.

For Hotel Guest Access: Offer temporary mobile keys. When a guest is away, authorized visitors can gain room entry via a time-sensitive QR code, elevating service quality.

In Gated Communities: Empower residents with a simple way to grant secure, temporary access to visitors, reducing front-desk bottlenecks and enhancing convenience.

Adaptable, reliable, and comprehensive, the HW-1820 is the forward-thinking solution to modern access challenges, designed to enhance both security and user satisfaction.
