| Brand Name: | HONORWAY |
| Model Number: | HW-1280 |
| MOQ: | 2 |
| Price: | $25/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs/month |
| Reading Performance | Specifications |
|---|---|
| Image Sensor | CMOS |
| Resolution | 1MP, 1280*800 pixels, 100fps |
| Decoding Capacity | Paper and screen barcodes including QR, PDF417, Data Matrix, EAN, UPC, Code 128, and all standard 1D/2D formats |
| Precision | 3mil |
| Light Source | 620nm Visible Red Diode LED |
| View Angle | 66°(H) * 50°(V) |
| Scan Angle | Rotation 360°, tilt ±65°, skew ±65° |
| Min Contrast | 20% |
| Trigger Mode | Manual, Continuous, Motion sensing, Host Mode |
| Typical Depth of Field | EAN13: 50-260mm, Code 39: 40-220mm, QR code: 25-320mm, PDF417: 30-180mm |
| Mechanical & Electrical | Specifications |
|---|---|
| Interface | TTL232, USB (KBW/COM) via 12pin FFC flat cable (0.5mm pitch) |
| Working Voltage | DC 3.3V |
| Current | 160mA (working), 20mA (USB standby), 2mA (TTL standby) |
| Dimensions | 21.6(W) * 16(D) * 12(H) mm |
| Weight | 3.5g |
| Indication | LED fill light with external buzzer and LED indicator trigger capability |
| Environmental Requirements | Specifications |
|---|---|
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% (Non-condensing) |
| Light Brightness | 0-100,000 LUX |
