| Brand Name: | HONORWAY |
| Model Number: | HW-1266C |
| MOQ: | 2 |
| Price: | 12usd/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 20Kpcs/month |
| Image Sensor | CMOS |
| Resolution | 640*480 pixels, 60fps |
| Decoding Capacity | Supports paper and screen barcodes 2D: QR, PDF417, Micro PDF417, Data Matrix, Maxicode, Aztec, Hanxin code, etc. 1D: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Industrial 2 of 5, Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar, and all normal 1D barcodes |
| Precision | 4mil |
| Light Source | 620nm Visible Red Diode with white LED illumination |
| View Angle | 60°(H) * 50°(V) |
| Scan Angle | Rotation 360°, tilt ±55°, skew ±55° |
| Minimum Contrast | 25% |
| Trigger Mode | Manual, Continuous, Motion sensing, Host Mode, etc. |
| Typical Depth of Field | EAN13 (13mil): 50-260mm Code 39 (5mil): 25-220mm QR code (20mil): 40-320mm PDF417 (6.67mil): 30-180mm Performance may vary based on barcode quality and environmental conditions |
| Interface | TTL232, USB (KBW/COM) via 12pin FFC flat cable (0.5mm pitch) |
| Working Voltage | DC 3.3V ± 0.3V |
| Current | 200mA (working Max) 10mA (USB standby) 1mA (TTL standby) |
| Dimensions | 21.4(W) * 16(D) * 12(H) mm |
| Weight | 3.5g |
| Indication | LED fill light (can trigger external buzzer and LED indicator) |
| Installation | 2pcs M1.6 screws, depth < 2mm |
