| Brand Name: | HONORWAY |
| Model Number: | HW-1266C |
| MOQ: | 2 |
| Price: | 12usd/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 20Kpcs per month |
| Reading Performance | Specifications |
|---|---|
| Image Sensor | CMOS |
| Resolution | 640*480 pixels, 60fps |
| Decoding Capacity | Supports paper and screen barcodes including QR, PDF417, Data Matrix, UPC, EAN, Code 128, Code 39, and all normal 1D/2D formats |
| Precision | 4mil |
| Light Source | 620nm Visible Red Diode, white LED for illumination |
| View Angle | 60°(H) * 50°(V) |
| Scan Angle | Rotation 360°, tilt ±55°, skew ±55° |
| Min Contrast | 25% |
| Trigger Mode | Manual, Continuous, Motion sensing, Host Mode |
| Typical DOF | EAN13 (13mil) 50-260mm, Code 39 (5mil) 25-220mm, QR code (20mil) 40-320mm, PDF417 (6.67mil) 30-180mm |
| Mechanical & Electrical | Specifications |
|---|---|
| Interface | TTL232, USB (KBW/COM) via 12pin FFC flat cable (0.5mm pitch) |
| Working Voltage | DC 3.3V ± 0.3V |
| Current | 200mA (working Max), 10mA (USB standby), 1mA (TTL standby) |
| Dimensions | 21.4(W) * 16(D) * 12(H) mm |
| Weight | 3.5g |
| Indication | LED fill light (can trigger external buzzer and LED indicator) |
| Installation | 2pcs M1.6 screws, depth < 2mm |
| Environmental Requirements | Specifications |
|---|---|
| Working Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% (Non-condensing) |
| Light Brightness | 0-100,000 LUX |
