| Brand Name: | HONORWAY |
| Model Number: | HW-1264N |
| MOQ: | 2 |
| Price: | 22-25 usd/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 10Kpcs per month |
| Image Sensor | CMOS |
| Resolution | 1MP 1280*720 pixels |
| Decoding Capacity | Supports paper and screen barcodes; OCR A/B optional |
| 2D Code Support | QR, PDF417, Micro PDF417, Data Matrix, Maxicode, Aztec, Hanxin code |
| 1D Code Support | EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5 |
| Precision | 4mil |
| Light Source | 620nm Visible Red Diode, red LED for illumination |
| View Angle | 45°(H) * 40°(V) |
| Scan Angle | Rotation 360°, tilt ±55°, skew ±55° |
| Min Contrast | 25% |
| Trigger Mode | Manual, Continuous, Motion sensing, Host Mode |
| Typical DOF | Code128 (5mil) 30-170mm, Code 39(4mil) 40-130mm, QR code(20mil) 30-210mm, PDF417(5mil) 30-120mm, MRZ code 120-220mm |
| Interface | TTL232, USB (KBW/COM) by 12pin FFC flat cable (0.5mm pitch) |
| Working Voltage | DC 3.3V ±10% |
| Current | Max 190mA (working), ≤1mA (TTL standby) |
| Dimensions | 21.2(W) * 14(D) * 10.2(H) mm |
| Weight | 3.5g |
| Indication | LED fill light (can trigger external buzzer and LED indicator) |
