| Brand Name: | HONORWAY |
| Model Number: | HW-1260D |
| MOQ: | 2 |
| Price: | 8-10 usd/pcs |
| Payment Terms: | T/T |
| Supply Ability: | 30Kpcs/month |
| Reading Performance | Image Sensor: CMOS Resolution: 640*480 pixels Decoding Capacity: Supports paper and screen barcodes |
|---|---|
| Supported Barcodes | 2D: QR, PDF417, Micro PDF417, Data Matrix (including reversed), Maxicode, Aztec, Hanxin code 1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5 |
| Precision | 4 mil |
| Light Source | 620nm Visible Red Diode, red LED for illumination |
| View Angle | 66°(H) * 50°(V) |
| Scan Angle | Rotation 360°, tilt ±65°, skew ±65° |
| Minimum Contrast | 25% |
| Trigger Modes | Manual, Continuous, Motion sensing, Host Mode |
| Typical Depth of Field | EAN13 (13mil): 50-260mm Code 39 (5mil): 25-220mm QR code (20mil): 40-320mm PDF417 (6.67mil): 30-180mm |
| Interface | TTL232, USB (KBW/COM) via 12pin FFC flat cable (0.5mm pitch) |
| Electrical Specifications | Working Voltage: DC 3.3V±0.3V Current: 160mA (working), 20mA (USB standby), 2mA (TTL standby) |
| Physical Dimensions | 21.4mm (W) * 13.2mm (D) * 12mm (H) Weight: 3.5g |
| Indication | LED fill light (can trigger external buzzer and LED indicator) |
| Working Temperature | -20°C to 60°C |
|---|---|
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% (Non-condensing) |
| Light Brightness | 0 to 100,000 LUX |
